• Dual display shows voltage/current and its frequency
• EF (Electric Field) detection
• VFD (Variable Frequency Drive) frequency measurement
• Low input impedance voltage measurement capable of attenuating the effects of ghost voltages
• Peak hold (Interval: 5 ms)
• Auto power save (30 min./Cancelable)

Technical Data:

Function	Range	Accuracy	Resolution
ACA	200.0 / 2000A	±(2.0%+5)	0.1A
DCA	200.0 / 2000A	±(2.0%+5)	0.1A
ACV	6.000 / 60.00 / 600.0 / 1000V	±(1.2%+5)	0.001V
DCV	6.000 / 60.00 / 600.0 / 1000V	±(0.5%+5)	0.001V
Resistance	600.0 / 6.000k / 60.00k / 600.0k / 6.000M / 40.00MΩ	±(0.5%+5)	0.1Ω
Frequency	10~1999Hz	±(0.1%+4)	0.01Hz
Capacitance	60n / 600n / 6μ / 60μ / 600μ / 2000μF	±(2.0%+5)	0.01nF



	Continuity Buzzer The buzzer sounds when the measuring object is electrically conducting.
	Data Hold A value indicated on the display is fixed even after the test lead is removed, and can be used as a record for reference purposes.
	Range Hold The range is fixed in the measurement of varying voltage and current which is difficult to read in the auto range.
	True RMS (True root-mean-square value) True RMS value. AC current and voltage of a non-sine wave can be measured by true RMS values.
	Frequency Expressed in the unit of Hz (hertz). Commercial frequency of 50Hz/60Hz can be measured.
	Capacitor Capacitor capacity (electrostatic capacity) is measured and expressed in the unit of F (farad), μF, etc.
	Measurement of relative value A certain measured value is assumed as 0 and measured values after that are expressed by positive or negative values relative the value fixed as 0.
	Backlight Allows indicator reading in a dark place.
	DC voltage Mark for clamp meters with DCV function.
	EF Function Non-contact AC voltage Detection
	DC/AC Measurable Both ACA & DCA are Measurable
	Peak Hold The peak value like in-rush current is indicated. The minimum pulse width capturable differs according to models.
	Automatic Measurement for DCV/ACV/Ohm The measurement function of DCV/ACV/Ωcan be automatically selected.
	Low-pass filter Low-pass filter cuts current value of high frequency.
